F663Nv3a FTTH Modem Router 1GE 3FE 1TEL WIFI F663 External Antenna GPON ONU ONT

Name: F663Nv3a FTTH Modem Router 1GE 3FE 1TEL WIFI F663 External Antenna GPON ONU ONT
Brand: GPON EPON ONT
SKU: F663NV3A
Price: 1.00 USD
Availability: InStock
Rating: 4.8 (122 reviews)

Quantidade de ordem mínima :	10pcs	Preço :	Negociatable
Detalhes da embalagem :	Caixa da caixa	Tempo de entrega :	15 dias
Termos de pagamento :	L/C, T/T	Habilidade da fonte :	20000pcs/Week

Lugar de origem:	guangdong	Marca:	GPON EPON ONT
Certificação:	CE ROHS Anatel	Número do modelo:	F663NV3A

Informação detalhada
Uso:	FTTX	tempo da garantia:	1year
Rede:	wifi	Cor:	Branco
Fonte de alimentação:	C.C. 12V/1A	Portos:	1GE+3FE

Descrição de produto

F663NV3a FTTH is a single-frequency and economical smart gateway specially built by ZTE for China Mobile. This model uses the new-generation self-developed chip, loads the intelligent operating system, and supports dynamic loading of plug-ins, and givess users with abundant home services. The stable wireless performance provides smooth Wi-Fi for the home. Its unique open application platform creates an operator-dominated and user-centered smart home application ecosystem. F663Nv3a FTTH Modem Router 1GE 3FE 1TEL WIFI F663 External Antenna GPON ONU ONT 0

Technical items	Descriptions
Brand	ZTE
Model	ZXHN F663NV3a
Fiber interface	SC/UPC
Fiber port	1 GPON interface, 1GE+3FE+1POT+1USB+WIFI,SC single-mode,
Fiber port	Downstream rate 2.5Gbps, Upstream rate 1.25Gbps
Wavelength	Tx 1310nm, Rx 1490nm
Voice protocol	SIP, H.248
RX sensitivity	<-27dBm (1490nm)
WLAN	IEEE802.11b/g/n,2*2 MIMO, 2.4G WIFI,external antenna
Net weight	≤0.6Kg
Configuration method	NMS, Web, or TR069
Power	≤8W
DC power	Adapter input: 100-240 V AC, 50 – 60 Hz ;
DC power	Adapter output: 11 – 14 V DC, 1 A
Button	Reset, power
Operation	Working temperature: -0-+40℃
Operation	working humidity:5-95%(non-condensation)
Dimension	25022065mm(lengthwidthheight)
L2 forwarding capability	Forwarding packets of any length at wire speed
IPv4 L3 forwarding capability	2Gbit/s with any length packets in downstream direction
IPv4 L3 forwarding capability	1Gbit/s with any length packets in upstream direction
IPv6 L3 forwarding capability	2Gbit/s with any length packets in downstream direction
IPv6 L3 forwarding capability	1Gbit/s with any length packets in upstream direction
LAN	1*10/100/1000Mbps adaptive Ethernet ports, full/half duplex, RJ45 interface
